I was satisfied with the IBIS, especially when paired with a Panasonic lens.

]]>
GH5 Panasonic camera, from anticipation to love or hate http://personal-view.com/talks/discussion/13179/gh5-panasonic-camera-from-anticipation-to-love-or-hate Tue, 16 Jun 2015 07:59:40 -0600 RRRoger 13179@/talks/discussions image

Specifications

  • 20Mp m43 CMOS sensor, no AA, 1.7x faster compared to GH4
  • 5 axis sensor based in-body image stabilization, 5 stops specified
  • in-camera waveform monitor and vector scope
  • 480fps AF sensor mode (only for prefocus and photos)
  • 200k actuations shutter, so GH5 is more in line with competition
  • Customisable My menu
  • 3.68Mdot EVF
  • 1.62Mdot 3.2" touch LCD
  • 2 SD slots, UHS-II compatible
  • 4k at 60,50,30,25 and 24fps, no cropping
  • 420 8-bit only at 4k p60
  • 422 10-bit mode for 4k 40fps and below video
  • 400Mbps All-I, 150Mbit IBC for 4K, but ir comes only with future firmware update
  • 1080p24 to 1080p180
  • VLOG will cost you extra $100
  • 6k photo mode at 30fps, continuous focus and exposure tracking enabled
  • 4k photo mode at 60fps
  • Splash, dust, freezeproof, magnesium alloy body
  • USB 3.1 gen 1 via USB-C connector
  • Wi-Fi 802.11a/b/g/n/ac, Bluetooth v4.2
  • Full-sized HDMI port with 4:2:2 10 bit output
  • 138.5mm x 98.1mm x 87.4 mm
  • 645g (bare), 725g (with card and battery)
  • $1999 for body

Preorders:

Camera page http://www.panasonic.com/global/consumer/lumix/gh5.html

Video modes


Previews:

]]>
Panasonic FZ2000 / FZ2500 / FZH1 4K 200Mbit ultrazoom topic http://personal-view.com/talks/discussion/15737/panasonic-fz2000-fz2500-fzh1-4k-200mbit-ultrazoom-topic Thu, 15 Sep 2016 12:33:52 -0600 Vitaliy_Kiselev 15737@/talks/discussions image

Specs

  • 1.0" 20.1mp BSI MOS sensor
  • 24-480mm F2.8-4.5 lens, 16 lenses in 11 groups
  • 9 aperture blades
  • Build in ND filter 0-1/64
  • 2.36mdot OLED EVF, 2.18x magnification (0.74x FF equivalent)
  • 3" 1.04mdot LCD
  • 12fps burst with fixed AF, 7fps continuous AF
  • 4K30p and FHD 60p video recording
  • 4:2:2 10-bit signal HDMI output
  • Wi-Fi
  • SD slot
  • $1199.99 at https://www.amazon.com/Panasonic-DMC-FZ2500-Digital-Camera-Megapixel/dp/B01LX7JSPJ/
  • November 28th release

Panasonic is introducing a second advanced compact camera, the FZ2500. This camera utilizes the same 20.1MP 1" MOS sensor as the LX10, but optimizes video performance with the inclusion of DCI 4K video recording and a true 24 fps frame rate, in addition to more conventional UHD 4K and Full HD recording modes. Also benefitting videographers, this camera includes Panasonic's CINELIKE D and CINELIKE V picture profiles for better grading capabilities, and V-Log L can be added via an optional upgrade. Additionally, high bit rate recording up to 200 Mbps is supported in both MP4 and MOV formats; video can be output over HDMI with a 4:2:2 10-bit signal; there is no recording duration limit; and a built-in ND filter can be used for enhanced control over exposure settings while recording.

More than just a video-optimized camera, however, the FZ2500 also sports a slew of specs for stills and movie users, such as a 50 fps continuous shooting rate with an electronic shutter, or 12 fps with a mechanical shutter, and an expanded sensitivity range of up to ISO 25600 for working in dim light. The built-in 20x Leica DC Vario-Elmarit f/2.8-4.5 lens covers a 24-480mm equivalent focal-length range, and 5-axis HYBRID O.I.S.+ controls the effects of camera shake for sharper handheld shooting. A free-angle 3.0" 1.04m-dot LCD touchscreen permits intuitive control and viewing ease from a variety of working positions, and a 2.36m-dot electronic viewfinder is also available. Additionally, built-in Wi-Fi also supports wireless image sharing and remote camera control.

]]>
Odd large horizontal lines in some videos shot on GH2 (Moon T7) http://personal-view.com/talks/discussion/16354/odd-large-horizontal-lines-in-some-videos-shot-on-gh2-moon-t7 Thu, 19 Jan 2017 20:54:57 -0700 airchase 16354@/talks/discussions I've started noticing this on some shots taken on my GH2 using the Moon T7 hack. I'm unsure if the lines are a result of the hack or not (I haven't tried it without it, and the issue appears to be inconsistent), but I was hoping someone here might have an idea and could shed some light on what may be happening.

Just looking at the video on its own, it's somewhat hard to tell. But if you're scrubbing through different shots, you can definitely see it. I made a gif comparing two identical shots, and you can clears see large dark yellow lines in the video: http://gifmaker.cc/PlayGIFAnimation.php?folder=20170119148rfTBjPEQ0fZEqE0dSjwXB&file=output_ZpFhpX.gif

Any ideas what could be causing this? I've seen this while shooting on 24p cinema as well as 720p@60fps at several different ISO and shutter speed values.

]]>
GH4 4K Panasonic video camera, official topic http://personal-view.com/talks/discussion/9542/gh4-4k-panasonic-video-camera-official-topic Tue, 04 Feb 2014 05:05:26 -0700 Vitaliy_Kiselev 9542@/talks/discussions image

Specs:

  • High speed 16Mp sensor
  • 2.36Mp OLED EVF
  • 1,036Mp OLED screem
  • 4K: 4096×2160 / 24 fps and QFHD 4K: 3840×2160 / up to 30 fps, up to 100Mbps
  • 1080p modes up to 96fps (in variable frame rate), up to 200Mbps I, or 100Mbps IBP modes (see below)
  • peaking with adjustments
  • 422 recording (external)
  • Stills - 12fps constant focus, 7.5fps - with focusing
  • Interface Unit with two XLR, 4 SDI
  • PAL/NTSC switchable
  • Weight with batteries - 560g
  • Dimensions - 133 mm x 93 mm x 84 mm
  • Wi-Fi and NFC
  • Price - unknown yet

Jump to post after official announcement - http://www.personal-view.com/talks/discussion/comment/158684#Comment_158684


Manuals:


We always have stock of GH4 bodies and/or kits,

PAL/NTSC
No time limits like US

Price: click on links below
Shipping: Shipping is around $50 for US/Canada/UK/Australia&NZ/Western Europe. Contact for any other regions.
I want to buy GH4.


Useful links

Available at:


Recording modes:

  • NTSC
    • MOV
      • [4K] 3840×2160, 29.97p, 100Mbps(IPB), LPCM,
      • [4K] 3840×2160, 23.98p, 100Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 59.94p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 29.97p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 23.98p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [4K] 3840×2160, 29.97p, 100Mbps(IPB), LPCM/AAC
      • [4K] 3840×2160, 23.98p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 59.94p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 29.97p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 23.98p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 59.94p, 28Mbps(IPB), AAC [FHD] 1920×1080, 29.97p, 20Mbps(IPB), AAC
      • [HD] 1280×720, 29.97p, 10Mbps(IPB), AAC
    • AVCHD
      • [FHD] 1920×1080, 59.94p, 28Mbps(IPB), Dolby Digital
      • [FHD] 1920×1080, 59.94i, 24Mbps(IPB), Dolby Digital (sensor output: 29.97fps)
      • [FHD] 1920×1080, 59.94i, 17Mbps(IPB), Dolby Digital (sensor output: 59.94fps)
  • PAL
    • MOV
      • [4K] 3840×2160, 25.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 50.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 25.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [4K] 3840×2160, 25.00p, 100Mbps(IPB), LPCM/AAC
      • [FHD] 1920×1080, 50.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 25.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 50.00p, 28Mbps(IPB), AAC
      • [FHD] 1920×1080, 25.00p, 20Mbps(IPB), AAC [HD]
      • 1280×720, 25.00p, 10Mbps(IPB), AAC
    • AVCHD
      • [FHD] 1920×1080, 50.00p, 28Mbps(IPB), Dolby Digital
      • [FHD] 1920×1080, 50.00i, 24Mbps(IPB), Dolby Digital (sensor output: 25.00fps)
      • [FHD] 1920×1080, 50.00i, 17Mbps(IPB), Dolby Digital (sensor output: 50.00fps)
  • Cinema
    • MOV
      • [C4K] 4096×2160, 24.00p, 100Mbps(IPB), LPCM
      • [4K] 3840×2160, 24.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 24.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [C4K] 4096×2160, 24.00p, 100Mbps(IPB), LPCM
      • [4K] 3840×2160, 24.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 24.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • AVCHD -
      • [FHD] 1920×1080, 23.98p, 24Mbps(IPB), Dolby Digital

Interview

Samples and videos


4K crop calculations:

Stills horizontal resolution - 4608
Cinema 4K horizontal resolution - 4096
4K horizontal resolution - 3840

This makes crop:

  • Cinema 4K - 1,125x
  • 4K - 1,2x

of course, it is additional crop (to 2x typical for m43), so you must multiple two if you need to know relative FF crop.


Previous related topics:

]]>
GH4 V-LOG contrast/gamma shift on external recorder http://personal-view.com/talks/discussion/16338/gh4-v-log-contrastgamma-shift-on-external-recorder Tue, 17 Jan 2017 23:03:15 -0700 AlexMcV 16338@/talks/discussions Heya,

Not sure if anyone else has encountered this, I've done a quick search and come up with nothin...

I've been using the atomos assassin with my GH4, and noticed that the footage from the assassin is slightly more contrasty/darker than footage recorded internally. I assume it's something the GH4 is doing, because it only seems to happen with V-LOG, not with standard. (I couldn't really be bothered checking with all the other colour modes...)

Here's a clip of me A/B-ing it on a premiere timeline with the scopes up. V-LOG, then standard. https://www.dropbox.com/s/hiugamp6hfbved4/gh4-assassin-contrast-level.mp4?dl=0

(obviously I don't own a colour chart, a set of pencils was the bet I could manage...)

This was recorded 8-bit, as it was the only way I could record both at the same time, but it happens with 10-bit too. At 4K as well as HD. Both the assassin and GH4 are running the most up-to-date firmware, as of Jan 2017.

Did I mess with some settings somewhere? Is my camera haunted? Is this something other people have noticed?

It doesn't actually bother me that much, I guess this is just a "what's up with that?" kinda question. So yeah. What's up with that?

]]>
Ask Nick Driftwood your questions about GH5 http://personal-view.com/talks/discussion/16283/ask-nick-driftwood-your-questions-about-gh5 Thu, 05 Jan 2017 07:36:53 -0700 Vitaliy_Kiselev 16283@/talks/discussions Here you can ask Nick Driftwood any questions considering GH5, starting right now.

As he has one of the few GH5 existing you can ask very specific things.

]]>
Panasonic LX100 camera topic http://personal-view.com/talks/discussion/11140/panasonic-lx100-camera-topic Wed, 27 Aug 2014 11:26:55 -0600 Tron 11140@/talks/discussions image

Previews

Available at:


]]>
Panasonic GX80, GX85, or even GX7 Mark II in Japan http://personal-view.com/talks/discussion/14903/panasonic-gx80-gx85-or-even-gx7-mark-ii-in-japan Fri, 01 Apr 2016 05:01:08 -0600 Vitaliy_Kiselev 14903@/talks/discussions image

Preliminary specs

  • 16Mp m43 CMOS sensor, no AA filter
  • 2.7Mp EVF
  • Sensor based 5 axis stabilization
  • 3" tilting touch screen
  • Wi-Fi
  • No microphone and headphone jack, only HDMI output
  • 8fps continuous shooting, 6fps with C-AF
  • 4Kp24, 4Kp25, 4Kp30, 100Mp max, 1080p60 at 50Mp.
  • Silent Mode, Multiple Exposure
  • Available in Black, Silver, Tan
  • Manufacturer price $799 for 12-32mm kit, UK - £509 body only, £599 with 12-32mm

  • Cheaper and better offer (unlimited ones!) at http://www.personal-view.com/deals/cameras/panasonic#panasonic-gx80-gx85

]]>
Can't decide between G85 and GH4. Any insight? http://personal-view.com/talks/discussion/16315/cant-decide-between-g85-and-gh4.-any-insight Tue, 10 Jan 2017 15:23:03 -0700 Magic815 16315@/talks/discussions So I've been a GH2 (hacked) user for about 5 years now, and want to make an upgrade while staying in the M43 ecosystem. (And keep the GH2 as a B-cam). My goal with the new camera will be to do Wedding Videography as well as low-budget short film narrative work (for the sake of this thread, let's say I put equal weight on weddings and short films).

Originally, my plan was to get a used GH4 (now that the GH5 is announced), but I'm reading up on the G85 and thinking it might be better in some regards. Let's say for simplicity that I can get a used GH4 for $800, or I can get a new G85 for $800 - so cost would be the same. Also, let's also assume that I likely wouldn't get the VLog upgrade or buy an external recorder if I went the GH4 route. If I had the extra funds for those (which I don't), I would probably just try and stretch a little further and get a GH5 sometime over the summer.

Knowing that I want to be doing wedding work, I've been considering getting a Metabones SpeedBooster Ultra 0.71x (Canon EF) and Sigma 18-35 f/1.8 (Canon EF) lens. I know M43's cameras are not great in low light, and not great at getting that shallow depth of field (both of which will be important for wedding videography), but my understanding is that that adapter+lens combo can help bring back at least some of that capability into any M43's camera I go with. (As an aside, I'm wanting to go with the Canon EF system because I have friends with Canon EF lenses that I can borrow, and I'm going with the Ultra because I want it to be the preferred adapter if/when I'm able to hopefully get a used GH5 in 1.5-2 years).

My main recording formats when filming would be 4K 24fps, or a high fps 1080p recording when I need slowed down footage. I plan to have the majority of my released films (both weddings and shorts) be in 1080p24fps, but I will be filming in 4K when I can so that I can scale down the footage to 1080p for the best results. I also expect there to be a some need for slowing down footage (especially when it comes to the wedding films), so I plan to occasionally use the 1080p high frame rate options with whichever camera I go with.

In terms of recording formats between the two, the GH4 obviously beats the G85, but I'm wondering if the G85 might still be good enough. It still has 1080p60fps (although at what looks to be a god-awful 28Mbps bit rate), and it has UHD 4K at 24fps at 100Mbps. The GH4 can do 1080p60fps at 100Mbps (can also do 200Mbps with All-I). Or the GH4 can push to 96fps at 100Mbps. And the GH4 has Cinema 4k at 24fps at 100Mbps.

Additionally, the GH4 has ports for both mic and headphone, whereas the G85 only has a mic jack. However, there seems to be a $50 workaround to get a headphone to work with the G85's HDMI-out. The GH4 is all metal, whereas the G85 still uses some plastic (although both are weatherproofed).

However, the IBIS and better low light on the G85 are very welcome benefits over the GH4. I've heard the EVF might be slightly better on the G85. And both have no recording limits (I'd be buying the US NTSC version). I believe both can display zebras and histograms, as well.

Are there any other major downsides with video on the G85 when compared with the GH4 that I'm not considering for my use case? I'm used to the GH2, so I'm sure there will be some "pro video" features that I might miss that I'm currently not thinking about. Any other reasons why I shouldn't go with the G85 that I'm not capturing above?

Thoughts?

]]>
Official Panasonic GH3 topic, series 3 http://personal-view.com/talks/discussion/5344/official-panasonic-gh3-topic-series-3 Sat, 01 Dec 2012 12:24:44 -0700 Vitaliy_Kiselev 5344@/talks/discussions This is continue of topics

http://www.personal-view.com/talks/discussion/4733/official-panasonic-gh3-topic-series-2#Item_1018
http://www.personal-view.com/talks/discussion/4592/official-panasonic-gh3-topic/p1

and


Also check

DR - http://www.digitalcamerainfo.com/content/Panasonic-Lumix-GH3-Digital-Camera-Review/Dynamic-Range.htm


Direct manuals links




Short Specifications

  • Effective Megapixels - 16.05 Megapixels (17.20 total)
  • Live MOS/17.3 x 13.0 mm (in 4:3 aspect ratio), not multi aspect
  • 200 - 12800 ISO
  • 3.0" 640k OLED Monitor with static touch control
  • 1.74Mp OLED EVF
  • Video - AVCHD 2.0 1080p50 (PAL), 1080p60 (NTSC), 1080p24 (with slow and fast variations, like 12fps and 50fps).
  • Three containers (AVCHD, MOV and MP4) and large bitrate modes, bot intraframe and interframe.
  • Shutter Speeds - 60-1/4000
  • Flash modes - Auto, Auto/Red-eye Reduction (when iA, iA+), Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction
  • Battery - Li-ion Battery Pack (7.2V, 1860mAh), old or new?
  • Continuous Shooting Speed - 6 fps
  • Weather Proof
  • WB - Auto, Daylight, Cloudy, Shade, Incandescent, Flash, White Set 1, 2, Color temperature setting
  • SD, SDHC, SDXC cards compatible
  • Dimensions - 132.9 x 93.4 x 82.0mm / 5.23 x 3.68 x 3.23 in
  • USB 2.0
  • Weight - 550g
  • Price - $1299 (body only!)

Available at:

Check other topic below for other countries and other US options:

http://www.personal-view.com/talks/discussion/4641/gh3-preordering-and-availability-topic


]]>
Timecode syncing multiple GH4 cameras http://personal-view.com/talks/discussion/14353/timecode-syncing-multiple-gh4-cameras Sat, 02 Jan 2016 17:56:58 -0700 DouglasHorn 14353@/talks/discussions What is the best way to timecode sync multiple GH4 cameras? From reading the manuals and related threads there seem to be two approaches:

App Method: Use the Lumix Link app to set the timecode for each GH4 to the time on the mobile device and then use Time of Day timecode mode.

YAGH Method: Use a YAGH to jam true timecode to the GH4 from a master clock.

The App Method seems easiest and cheapest if it is accurate enough. Has anyone tried it yet with multiple GH4s?

If the App Method doesn't sync cameras with sufficient accuracy, do you need a YAGH for each camera, or can you attach the YAGH to a GH4 to jam timecode and, once that camera's clock is set, move the YAGH to the other cameras in turn to jam sync timecode. In other words, once the GH4's timecode is set via the YAGH, does the camera retain it when the YAGH is removed? This would let one YAGH serve multiple cameras for timecode jamming purposes.

Thanks!

]]>
Why Panasonic exposure so simple and limited? http://personal-view.com/talks/discussion/15142/why-panasonic-exposure-so-simple-and-limited Sat, 28 May 2016 12:33:19 -0600 Vesku 15142@/talks/discussions GH3, GH4 and other high end/professional Panasonic cameras has severe limitation in video exposure options and features. Many pocket cameras and cell phones has more versatile exposure. Why Panasonic has decided to leave many basic exposure tools out of the tool box? Lets look the GH4:

-not showing basic exposure information (aperture, shutter and iso).

-no auto iso in M with EV comp although it has a dedicated EV comp button. In fact I can not find any other reasonable use for that button than EV comp with auto iso in M.

-no iso limit like in photo modes.

-AE lock button works crippled.

-full auto uses very high shutter speeds.

-no shutter speed limit.

-all special features like long shutter speeds or slow motion works only after everything (AE+AF) is in manual.

-all Panasonic objectives has stepping aperture.

It cant be a lack of knowledge. Panasonic has limited exposure options in purpose. But why?

]]>
GH3 with dead LCD (flex cable issue) http://personal-view.com/talks/discussion/16316/gh3-with-dead-lcd-flex-cable-issue Tue, 10 Jan 2017 16:27:40 -0700 EspenB 16316@/talks/discussions First of all I had the wobbly GH3 LCD hinge which was repaired under warranty a couple of years ago.

However, when I got it back after repair (in 2014?) the LCD did not turn on when it was extended away from the camera body. I shipped it in for repair again and as far as I recall the complete hinge assembly with cable was replaced. Now the LCD worked correctly again.

Summer of 2016 the LCD went dead again. However some light tapping/knock shock to the side of the body/hinge makes the LCD turn on again in some positions, but the colors are sometimes posterized or the image is darker than normal. There is no wobbly hinge, but it seems that the flex cable in the hinge has issues yet again.

Looking for parts on ebay I find both the flex cabel as a separate part and the flex cable allready attached to the hinge assembly.

Do anyone have experience replacing the complete hinge with flex cable?

Also, I'm kind of disappointed about the flex cable malfunctions. Is this a typical problem of cameras with rotating LCDs? Looking at the GH3 flex cable parts on ebay they seem to sell a lot...

]]>
Panasonic G80 / G85 / G8 4K 5-axis stab magnesium monster http://personal-view.com/talks/discussion/15524/panasonic-g80-g85-g8-4k-5-axis-stab-magnesium-monster Tue, 16 Aug 2016 06:30:43 -0600 Vitaliy_Kiselev 15524@/talks/discussions image

Specifications

  • 16mp m43 CMOS sensor without low pass filter
  • Sensor based 5-axis stabilization, around 5 stops
  • Improved 2.36Mpix OLED EVF
  • 3" 1Mdot LCD
  • Dual IS to work with lens IS improved to V2
  • 4kp30, p24, 1080p60,p50 recording in MP4 up to 100Mbit, recording with 422 color encoding
  • 422 recording, but not 10 bit as GH5, only 8bit
  • 9fps shooting
  • SD card slot with latest UHS support
  • Usual Panasonic DFD tech
  • Microphone socket, headphone socket
  • Dust and water proof, magnesium body

PV Deals

  • Body (black PAL, non EU, no limit) - $880 $799
  • 14-140mm Kit (black PAL, non EU, no limit) - $1180 $1099

Both at http://www.personal-view.com/deals/cameras/panasonic#panasonic-g80-g85-g8

US Amazon


]]>
Xiaoyi YI-M1 m43 camera, 4K video, $329 for kit http://personal-view.com/talks/discussion/15720/xiaoyi-yi-m1-m43-camera-4k-video-329-for-kit Tue, 13 Sep 2016 18:40:53 -0600 Vitaliy_Kiselev 15720@/talks/discussions image

Specs

  • Sensor - m43 20Mp IMX269 by Sony (same as in latest Panasonic cameras)
  • 81 AF points
  • 3840 × 2160 30fps 70Mbit, 2048 × 1536 30fps 30Mbit, 1920 × 1080 60fps video H.264, 30Mbit
  • Peaking for video
  • 1.04mdot LCD touch screen
  • 1/4000s ~ 60s shutter speed
  • 1/125s flash sync, external flash
  • 5fps burst shooting
  • HDR shooting
  • Wi-Fi, Bluetooth including LE support
  • Remote control via smartphone app
  • SDHC card slot, max size - 512GB
  • USB 2.0 connector, HDMI output
  • Both mike and headphone ports are absent
  • 113.5mm (W) x 64.3mm (H) x 33.6mm (D)
  • 280g
  • standard kit with 12-40mm lens - $329
  • double kit also have 42.5mm F1.8 macro - $449

http://www.xiaoyi.com/weidan.html

]]>
Panasonic FZ80 with 4K recording http://personal-view.com/talks/discussion/16268/panasonic-fz80-with-4k-recording Tue, 03 Jan 2017 21:41:17 -0700 Vitaliy_Kiselev 16268@/talks/discussions image

Specs

  • 1/2.3" 18Mp BSI-CMOS Sensor
  • Venus Engine
  • 3" 1,04Mpix LCD touch screen
  • 1,166Mpix EVF
  • 4K p30 at 100MBit video, 1080p60-30 modes at 28MBit
  • No mike input, no headphone output
  • 802.11b/g/n Wi-Fi
  • 616 g
  • 130 x 94 x 119 mm
  • $399

Preorder https://www.amazon.com/Panasonic-DC-FZ80K-Lumix-Camera-F2-8-5-9/dp/B01MS16V42/

PR

Panasonic has today announced the new LUMIX FZ80 from the popular FZ series that packs a powerful optical zoom and superior controllability, including manual operation over photo and video recording. The LUMIX FZ80 features the exceptionally-versatile LUMIX DC VARIO 20mm ultra wide-angle lens with a 60x optical zoom (35mm camera equivalent: 20-1200mm), which makes it possible to capture dynamic landscapes, wild animals and birds from a distance.

The newly integrated 18.1-megapixel High Sensitivity MOS Sensor and advanced image processor Venus Engine also achieve high-speed response and high-quality images even in high-sensitivity recording.

For an even faster response and higher mobility, the LUMIX FZ80 boasts a high-speed, high-precision AF with DFD (Depth From Defocus) technology[1], which shortens the focusing time. It calculates the distance to the subject by evaluating two images with different sharpness levels at a high 240-fps signal exchange speed. As a result, the LUMIX FZ80 achieves an AF of approximately 0.09 sec[2]. This benefit increases as the focal length grows.

The LUMIX FZ80 also offers high-speed burst shooting at 10-fps (AFS) / 6-fps (AFC) to capture fast-moving subjects in crisp focus. Thanks to the touch-control system, users can quickly focus right on the subject and even release the shutter with touch operation to capture fleeting photo opportunities.

The LUMIX FZ80 records smooth, high-resolution QFHD 4K videos in 3840x2160 resolution at 30p. The powerful 60x optical zoom and POWER O.I.S. (Optical Image Stabilizer) with Active Mode suppresses blurring, even in video recording. Taking advantage of 4K technology, users can enjoy 4K PHOTO shots and a variety of derivative functions, such as the new Focus Stacking, Post Focus, Light Composition, and 4K Live Cropping. For more creative freedom, Creative Control and Creative Panorama options are available.

The LUMIX FZ80 also integrates a 1,040K-dot rear monitor with touch-control system. Together with the 0.2-inch 1,170K-dot EVF (Electronic View Finder), users can capture subjects in clear focus. It also includes Wi-Fi® connectivity to offer a more flexible shooting experience and instant image-sharing with easy operation. With hot shoe and compatibility with a variety of optional accessories, the LUMIX FZ80 goes beyond a standard telephoto zoom compact camera while providing high-quality photos and an exceptional 4K video recording experience.

Mitigate distances with a powerful 60x optical zoom lens

The LUMIX FZ80 features the stunningly versatile LUMIX DC VARIO 20mm ultra wide-angle lens with a 60x optical zoom - both as photos and video footage. The 20mm ultra wide-angle lens captures an approx. 140% wider angle of view compared with a 24mm angle of view. The POWER O.I.S. (Optical Image Stabilizer) with Active Mode effectively suppresses hand-shake vibration both in photo and video recording.

The Intelligent Zoom is included with the LUMIX FZ80, which extends the zoom ratio up to 120x equivalent, maintaining high picture quality even when combining a digital zoom.

Capture unmissable moments with high-speed response, 4K PHOTO and 4K video

The 18.1-megapixel High Sensitivity MOS Sensor is newly-integrated into the LUMIX FZ80. Together with the high-performance image processing LSI Venus Engine, it elevates the response, sensitivity and image quality to an even higher level. Incorporating high-speed digital signal output technology, the FZ80 shoots 10 (AFS) / 6 (AFC) fps in 18.1-megapixel full resolution with a mechanical shutter.

Taking advantage of 4K technology, users can enjoy 4K PHOTO shots with the LUMIX FZ80. 4K PHOTO lets the user capture fleeting photo opportunities at 30 fps by extracting the best frame from a 4K burst file to save as a photo. Plus, multiple images can be automatically saved as 4K PHOTO shoots all at once. A maximum of 150 frames in five seconds can be saved following a designated frame.

It also comes with the Post Focus function, which enables users to select the in-focus area even after shooting. This is helpful especially in macro shooting where strict focusing is required or for changing expressions by changing the focused subject. This function has been developed by combining the high-speed, high-precision DFD (Depth From Defocus) auto focus technology with 4K technology. Both Post Focus and Focus Stacking can be activated quickly with the dedicated button on the top panel.

The LUMIX FZ80 also records stunningly smooth, high-resolution QFHD 4K videos in 3840x2160 resolution at 30p in addition to Full-HD 1920x1080 videos at 60p in AVCHD Progressive or MP4 (MPEG-4 / H.264) format with practical full-time AF.

The LUMIX FZ80 enables 4K Live Cropping in video recording to achieve stable panning or zooming in video recording. Thanks to its digital operation, panning and zooming images are smooth because it does not physically move the zoom lens.

A variety of video recording options are also available for users to choose from - High Speed Video, Time Lapse and Stop Motion Animation. High Speed Video records subjects in fast motion at 120fps.

Take amazing images and video even under strong sunlight

Equipped with a static-type touch-control system, the 3-inch rear screen with 1040K-dot high resolution features an approximately 100% field of view. The touch-control system lets the user immediately focus on a subject and even release the shutter by simply touching the screen.

The LUMIX FZ80 also has a 0.2-inch LVF (Live View Finder) with a magnification ratio of approx. 2.59x / 0.46x (35mm camera equivalent in 4:3) in 1170K-dot equivalent high resolution, 100% field of view. Thanks to the high 60-fps frame rate, image lag is also minimized making it suitable for shooting fast-moving subjects under strong sunlight.

Full manual control is available with LUMIX FZ80 to enjoy more creative photography. The design of the grip has also been re-engineered for stable holding during extended shooting.

Other Features

Easy Wireless Connectivity via Wi-Fi® with Smartphones
The LUMIX FZ80 integrates Wi-Fi® connectivity (IEEE 802.11 b/g/n) to provide a more flexible shooting experience and instant image sharing with easy operation. Once the camera and a smartphone or tablet are connected, installing Panasonic's dedicated application, Panasonic Image App for iOS / Android, users can shoot, browse and share images remotely. Users can also upload images to a variety of social media services right on the spot.

AC/USB Power Charging
The camera’s battery can be recharged either via AC or USB based on the users’ preference.

The FZ80 will have a black body and will be available in March for $399.99.

]]>
Is there any DC power input for the GH5? http://personal-view.com/talks/discussion/16285/is-there-any-dc-power-input-for-the-gh5 Thu, 05 Jan 2017 14:21:54 -0700 sbrenner 16285@/talks/discussions I suppose one could use a dummy battery for that but it would be nice to have a dedicated dc input. Seems like continuous shooting might be limited by battery life (especially so for mirrorless). And I guess you could hot swap a battery in a grip but that seems awkward.

]]>
Panasonic G7 topic, 4K castrate monster or GH4 for poor http://personal-view.com/talks/discussion/12408/panasonic-g7-topic-4k-castrate-monster-or-gh4-for-poor Wed, 18 Feb 2015 01:13:35 -0700 Vitaliy_Kiselev 12408@/talks/discussions image

Specifications

  • 2160p30 (in NTSC), 2160p25 (in PAL), 2160p24, 100Mbit
  • 1080p24/1080p60 at up to 28Mbit only (sic!)
  • Focus Peaking
  • P/A/S/M mode for Video Recording
  • Time Lapse Shot / Stop Motion Animation
  • Sensor and LSI same as in GH4
  • Simpler firmware with less features
  • 2.36 OLED EVF
  • Tiltable LCD screen instead of AMOLED
  • UHS-II SDXC Memory Card Compliance
  • 3.5mm Microphone Socket (no headphone one!)
  • 30min recording limit
  • Weight - 410g
  • Dimensions - 125 x 86 x 77 mm
  • $699 body, $799 kit
  • Black - http://www.amazon.com/gp/product/B00X409PQS/
  • Silver - http://www.amazon.com/gp/product/B00X409O6O/

G7 kits are available in PV deals (as usual, cheaper and with free delivery to many countries)

http://www.personal-view.com/deals/cameras/panasonic#panasonic-g7

NTSC bodies are unlimited (including 4K and all).

It is both NTSC and PAL bodies, PAL do not have 30min limits in AVCHD only.

]]>
Panasonic GX800, GX850 aka GF9, first GF to shoot 4K http://personal-view.com/talks/discussion/16246/panasonic-gx800-gx850-aka-gf9-first-gf-to-shoot-4k Thu, 29 Dec 2016 01:59:31 -0700 Vitaliy_Kiselev 16246@/talks/discussions image

Specs

  • 16MP m43 sensor, no low pass filter
  • 4K 30p and 24p, 1080p60 video, again fixed by region you buy to PAL or NTSC
  • AF with DFD
  • 5-axis Dual I.S.
  • 180 degrees tiltable low resolution 1.04mdot 3.0" touch LCD panel
  • 4K PHOTO
  • Wi-Fi 802.11 b/g/n
  • Battery charging only via USB
  • 106.5 x 64.6 x 33.3 mm
  • 239 g body only weight
  • Black and Orange
  • Double lens kit 12-32mm+25mm F 1.7 kit
  • 12-32mm F3.5-5.6 kit price is $549

Preorder

Hands-ons:


]]>
Panasonic LX10 / LX15 / LX9 http://personal-view.com/talks/discussion/15730/panasonic-lx10-lx15-lx9 Wed, 14 Sep 2016 20:30:56 -0600 Vitaliy_Kiselev 15730@/talks/discussions image

Specifications

  • 1.0" 20.1mp MOS sensor
  • 8.8-26.4mm F1.4-2.8 lens, 11 lenses in 9 groups, 4 aspherical lenses, 2 aspherical ED lenses, one UHR lens
  • 5-axis hybrid Power OIS
  • 3" 1.04mdot tilting LCD, 180 degrees for selfies
  • 4K 30fps, 1080p60 absolutely no improvements
  • 4K Photo mode at 30fps, up to 15 minutes
  • Minimum focusing distance is from 30cm up to 3cm in macro mode
  • 1/4,000 min shutter speed, up to 1/16,000 in electronic shutter mode
  • Wi-Fi
  • USB charging now to save on charger
  • SD cards slot, UHS-I compatible
  • 105.5 x 60 x 42 mm
  • 280g bare body weight, 310g real weight

Our deals

$650 at http://www.personal-view.com/deals/cameras/panasonic#panasonic-lx10-lx15

US Amazon

$699 at https://www.amazon.com/Panasonic-DMC-LX10K-Megapixel-24-72mm-1-4-2-8/dp/B01LZHIX13/

]]>
GH4 Firmware 2.3, V-log for $99, Epic Panasonic marketing fail http://personal-view.com/talks/discussion/12795/gh4-firmware-2.3-v-log-for-99-epic-panasonic-marketing-fail Mon, 13 Apr 2015 11:37:41 -0600 shian 12795@/talks/discussions End of April 2015. Conflicting reports on V-log, but true Anamorphic mode

Further text added by VK:

How to set V Log for free

Update camera firmware to v2.3 if you did not do this already Install Panasonic app on smartphone Connect camera with the application
Go to picture profile and set V-LOG L
Save this setting to C1 to make it work without app.

PR

Panasonic announced the release of a much anticipated firmware update Ver.2.2 for the award winning LUMIX GH4. This new firmware enables two new features, most notably the ability to record anamorphic video content.

Anamorphic lenses are used to create a cinemascope aspect such as 2.39:1 or 2.35:1. Panasonic discovered that cinematographers had been experimenting with the 4K PHOTO mode 4:3 aspect ratio in the LUMIX GH4 and vintage anamorphic cine lenses to achieve the classic Hollywood look of anamorphic film capture. Unlike complex digital post processing needed to achieve the look, many of the background distortion and light flare effects that became so popular with anamorphic film capture can now be achieved optically in the LUMIX GH4.

Thanks in part to its Micro Four Thirds format and 4K recording ability, firmware Ver.2.2 for the LUMIX GH4 enables an Anamorphic (4:3) Mode capable of recording video in 3328 x 2496 pixel (equivalent to approx. 8.3-megapixel) resolution at a frame rate of either 23.98, 24, 25 or 29.97 fps. With an anamorphic lens such as 2x1 you can capture and un-squeeze a 3356x2496 image in post-production. In addition, 4:2:2 / 10 bit HDMI output is also available2.

A further enhancement of the new firmware is the addition of a very high shutter speed of 1/16,000 sec. when using its electronic shutter mode.

]]>
GH2 720p upscaling: great high quality affordable plugin http://personal-view.com/talks/discussion/16160/gh2-720p-upscaling-great-high-quality-affordable-plugin Sat, 10 Dec 2016 17:33:50 -0700 apefos 16160@/talks/discussions For the low budget people who are using GH2 these days:

GPUresize is a plugin for Premiere and After Effects. It has a new feature called stairstep upscaling. This feature combined with the built in Kaiser upscaling algorithm deliver amazing results for upscaling 720p to 1080p. The annoying aliasing almost disapears.

http://www.aescripts.com/gpuresize/

Test the trial version with this footage to see the results (slow the footage to 24p/25p/30p and compare the upscaling render without and with GPUresize kaiser+stairstep):

http://216.18.212.226/PRODS/DMCGH2/FULLRES/yvidDMCGH2_720p_HQ_00015.MTS

]]>
GX1's wrting speed is lower than GF2 with a same card http://personal-view.com/talks/discussion/16227/gx1s-wrting-speed-is-lower-than-gf2-with-a-same-card Sat, 24 Dec 2016 09:14:46 -0700 Mitchell718 16227@/talks/discussions Hi everyone, Merry Christmas!!

I owned a GF2 since 2012 and bought a used GX1 recently for video shooting.

I hacked my GF2 with settings with over 100 Mbps in MP4 and the gear worked well with my Sandisk 45m/s card (U-1) Then I hacked the GX1 with the same setting (for example, driftwood's MOON T9) and used the same Sandisk 45 m/s card. Surprisingly GX1 always showed writing error due to card speed, which never happened with my GF2! I tried several lower mbps settings at around 60-70 mbps with my GX1, no writing error came up, but the video became very unsmooth when played in my computer. The unsmooth playback is obviously caused by the insufficient writing speed during recording.

Quite confused that GX1, a camera supporting SDXC U1 card, could have insufficient wrting speed problem which never happens with GF2, an older model without SDXC card support.

I know GX1 is not a gear metioned often here, but I still would like to know any GX1 owner or any expert ( like @Vitality_Kiselev or @Driftwood :)) could help with it.

BTW, this is my first post and I would like to take the chance to thank every setting provider like @Vitality_Kiselev , @Driftwood for bringing my GF2 to a new level of videography. I have so much fun with it!!!

Thank you!

]]>
4K Photo solves many issues with video http://personal-view.com/talks/discussion/16152/4k-photo-solves-many-issues-with-video Thu, 08 Dec 2016 16:01:04 -0700 Vesku 16152@/talks/discussions I figured that using 4k photo feature I can shoot normal 4k 30P videos with many useful features which are lacking in normal video mode:

  • Auto iso in M
  • Auto iso upper limit (no more camera running easily to iso 6400)
  • Shows all exposure values in all modes
  • Changing PASM modes for video just turning mode dial
  • Different aspect ratios 1:1 4:3 3:2
  • Toggling video/photo camera just pressing FN-button (4kphoto on/off)
  • I can have more presets for video (PASM + C memories)
  • When playing video I can zoom in with any frame
  • Showing frame exif when extracting image from video

I must test if the 4k photo has any drawbacks. Playing videos with camera is not so easy than with normal videos. The 4k video file is the same as normal mp4 100Mbs 30P video with levels 0-255. Cine profiles are not included but I use Natural anyway.

]]>
Replacement LCD panel for GH1 http://personal-view.com/talks/discussion/5319/replacement-lcd-panel-for-gh1 Wed, 28 Nov 2012 01:46:43 -0700 fredkaf 5319@/talks/discussions hi everybody , i'm looking around the web to find a new lcd screen for my GH1 .. mine as broken .. but i couldn't find it even on ebay or other .. my search " GH1 lcd panel " am i right ? ( i'm french so .. lol )

any help are welcome

fred ++

]]>
Just need longer recordig (and clean HDMI) for GH2 http://personal-view.com/talks/discussion/16163/just-need-longer-recordig-and-clean-hdmi-for-gh2 Sun, 11 Dec 2016 11:44:07 -0700 swschilke 16163@/talks/discussions Dear *,

Just got a used GH2 and I wonder which GH2 hack gives me just longer recording and my second wish: clean HDMI out (preferable without recording on SD card). Any recommendations? Which is nowadays the "best" hack I could use?

Kind regards

sws

]]>
Panasonic 4k Codec Breaks: 100Mbps is not enough http://personal-view.com/talks/discussion/16153/panasonic-4k-codec-breaks-100mbps-is-not-enough Fri, 09 Dec 2016 09:57:37 -0700 apefos 16153@/talks/discussions Panasonic 4k Lumix cameras could have a little more datarate...

In every last two B frames in the each GOP the image breaks into some mud when there are details.

It seems Panasonic is using GOP 12: " IBB PBB PBB PBB " and in the last two "BB" frames the codec does not handle the image.

This issue keeps repeating two times each second and makes the image jumps two times each second, very annoying.

See the frame grabs from G7 4k footage (a crop from 4k frames), the P frame is ok, the I frame is ok, but the B frames are bad:

]]>
Panasonic GX8 camera official topic http://personal-view.com/talks/discussion/13380/panasonic-gx8-camera-official-topic Tue, 14 Jul 2015 08:42:41 -0600 Riker 13380@/talks/discussions image

  • 20 Megapixel sensor
  • Dual IS (on sensor and on lens working together)
  • 1/16000 sec High Shutter Speed using Electronic Shutter
  • 2.36 million dot organic EL tilting EVF
  • 21mm Eyepoint LVF for improved usability with glasses
  • Dust and water resistant
  • magnesium alloy body
  • 4K Photo
  • 4K Video
  • Focus Peaking
  • 2.5mm Microphone Socket
  • Silent Mode
  • Free Angle 1.04 million dot organic EL monitor
  • Wi-Fi, NFC, QR code connection
  • Continuous shooting 8 frames / sec in the AF tracking
  • Time Lapse Shot / Stop Motion Animation
  • Body color is black and silver
  • Very good prices for kits on deals - http://www.personal-view.com/deals/cameras/panasonic#panasonic-gx8


My lordy lord. Best compact for m43 user ever made? Seems like it. There's no audio jack but who actually cares about that on a camera of this size for its intents and purposes.

]]>
Panasonic AG-UMR20 POV cam and recorder http://personal-view.com/talks/discussion/16120/panasonic-ag-umr20-pov-cam-and-recorder Wed, 30 Nov 2016 04:48:58 -0700 Vitaliy_Kiselev 16120@/talks/discussions image

More info (in Japanese)

http://news.panasonic.com/jp/press/data/2016/11/jn161104-4/jn161104-4.html

http://panasonic.biz/sav/broch_bdf/ag-umr20_uck20.pdf

]]>
