Panasonic Sun, 18 Feb 18 18:51:57 -0700 Panasonic en-CA Panasonic GH5S GH5 S, 4K Video Edition Mon, 27 Nov 2017 05:11:09 -0700 Vitaliy_Kiselev 18330@/talks/discussions

This is a low light version of the GH5.


Crop values

  • 3680 pixel long in 4/3 = 2x crop factor in 4/3 still mode
  • 3840 pixel long in 3/2 = 1,91x crop factor in 3/2 still mode
  • 4016 pixel long in 16/9 = 1,832x crop factor in 16/9 still mode
  • 4096 pixel long in 17/9 = 1.796x crop factor in 17/9 (DCI 4K) video mode
  • 3840 pixel long in 3/2 = 1,91x crop factor in 16/9 4K UHD video mode.
  • Speed Booster Ultra + GH5s + DCI 4K = crop factor of 1,275x with 35mm lenses.
  • Speed Booster XL + GH5s + DCI 4K = crop factor of 1,149x with 35mm lenses.

Available for preorder at

Wishes for the GH6 Thu, 12 Oct 2017 00:05:54 -0600 AKED 17968@/talks/discussions Everybody is working and talking about the 2.0 and now 2.1 firmware update for the GH5.

But for sure the Panasonic engeneers are alreday working on the GH6. For Panasonic claims and has prooven, that they listen to the customers, let us tell them early in the process of the development, what features we would like to see in the GH6, that can not be implemented in the GH5 through firmware update.

Let me start with a wish for a 2nd screen:

I think it is great to have the controls like waveform, histogram, sound etc. to have all the settings in sight, but as we all know, they take up a lot of space and cover up the video picture on the screen.

So my idea is, to have a second screen on the body where the screen normally rests. So that, when the normal, video screen, is flipped in, they face each other.

I would call it a "service screen", where you can have and see all the helping tools without covering the screen with the picture. All other settings like aputure, ss, ISO etc could also be shown and maybe one can also change the settings of the camera on that screeen. As you like. One should be able to assign, what you want to see on that screen.

I would make it a touch screen as well, so that the camera would have a double touch-screen, so the you can move things to the video screen if you need it, for example when you do overhead work and can not see the service screen but need the wave or sound controls. Once you are back in normal use, you can push them out of the way to the service screen again. If you do not need it, you could switch it off to save battery.

Nowadays, screens are so thin, that I doubt that it would make the camera bigger.

I think this would be a great help to have all the controls in sight, without them covering the main video screen.

Also, NO other Mirrorless or DSLR camera has that feature which would really give Panasonic another advantage over his competitors.

One could also think about transmitting the information of the service screen maybe via bluetooth to a mobile device, so one can have it in sight if a look on the camera is difficult or a 2nd person can have a look or even adjust the settings, while the camera man takes care of the framing.

What do you think about this? Would that make sense and help?

Z Camera E1 Mini m43 4K camera for $249 only, cheapest 4K ever Tue, 21 Nov 2017 07:38:26 -0700 Vitaliy_Kiselev 18293@/talks/discussions image

  • Three selectable video noise reduction levels
  • Low 200 millisecond latency when using app
  • Single, Continuous Center, and Flexible Zone autofocus modes
  • microSD/SDHC/SDXC card slot
  • Two 2000mAh rechargeable battery packs included
  • Mini-HDMI 1.4a port supports clean 1080p output
  • Micro-USB 2.0 port
  • 3.5mm mic input
  • Expansion port
  • DC power input for external power source (5V, 2A)

Panasonic DC-GX9 camera - first Panasonic that stops from overheating Sun, 28 Jan 2018 20:24:17 -0700 Vitaliy_Kiselev 18885@/talks/discussions image


Panasonic G9, m43 4K monster with LCD on top Sun, 29 Oct 2017 11:02:49 -0600 Vitaliy_Kiselev 18085@/talks/discussions image


Video modes

  • 3840 x 2160 @ 60p at 150 Mbps, MP4, H.264, Linear PCM
  • 3840 x 2160 @ 30p at 100 Mbps, MP4, H.264, AAC
  • 3840 x 2160 @ 23.98p at 100 Mbps, MP4, H.264, AAC
  • 1920 x 1080 @ 60p at 28 Mbps, MP4, H.264, AAC
  • 1920 x 1080 @ 30p at 20 Mbps, MP4 or AVCHD, H.264, AAC
  • 1920 x 1080 @ 60i at 24 Mbps, AVCHD, MTS, H.264, Dolby Digital
  • 1920 x 1080 @ 60i at 17 Mbps, AVCHD, MTS, H.264, Dolby Digital
  • 1920 x 1080 @ 23.98p at 24 Mbps, AVCHD, MTS, H.264, Dolby Digital


Panasonic DC-TZ200 aka TZ220 and ZS200 Sun, 28 Jan 2018 20:25:44 -0700 Vitaliy_Kiselev 18886@/talks/discussions image


  • 20Mp 1.0" CMOS sensor
  • GH5 LSI used
  • 24-360mm 15X optical zoom ( 1 aspherical ED lens, 5 aspherical lenses and 3 ED lenses)
  • 5 axis HYBRID O.I.S. + stabilizer
  • 2.3Mdot EVF. 1.45x magnification (or 0,53x in 35mm terms)
  • 3" 1.24Mdot touch LCD
  • New linear motor for silent fast AF
  • Spatial recognition AF
  • 3cm macro mode
  • 4K30p video (100Mbit) / 4K photo, 1080p120fps mode
    • 3840 x 2160 @ 30p / 100 Mbps, MOV, H.264, AAC
    • 3840 x 2160 @ 24p / 100 Mbps, MOV, H.264, AAC
    • 1920 x 1080 @ 60p / 28 Mbps, MOV, H.264, AAC
    • 1920 x 1080 @ 60p / 28 Mbps, AVCHD, MTS, H.264, Dolby Digital
    • 1920 x 1080 @ 60i / 17 Mbps, AVCHD, MTS, H.264, Dolby Digital
    • 1920 x 1080 @ 30p / 20 Mbps, MOV, H.264, AAC
    • 1920 x 1080 @ 30p / 24 Mbps, AVCHD, MTS, H.264, Dolby Digital
    • 1920 x 1080 @ 24p / 24 Mbps, AVCHD, MTS, H.264, Dolby Digital
    • 1280 x 720 @ 30p / 10 Mbps, MOV, H.264, AAC
  • Wi-Fi and Bluetooth
  • Two tiny stereo microphones located on top (bad!)
  • No microphone input or headphone output
  • 111.2mm x 64.4mm x 45.2mm
  • 340g
  • Available for $ 799 at


Panasonic 1" TZ100 ZS100 ultrazoom official topic Wed, 30 Dec 2015 03:17:44 -0700 Vitaliy_Kiselev 14324@/talks/discussions image



Panasonic GX80, GX85, or even GX7 Mark II in Japan Fri, 01 Apr 2016 05:01:08 -0600 Vitaliy_Kiselev 14903@/talks/discussions image

Preliminary specs

  • 16Mp m43 CMOS sensor, no AA filter
  • 2.7Mp EVF
  • Sensor based 5 axis stabilization
  • 3" tilting touch screen
  • Wi-Fi
  • No microphone and headphone jack, only HDMI output
  • 8fps continuous shooting, 6fps with C-AF
  • 4Kp24, 4Kp25, 4Kp30, 100Mp max, 1080p60 at 50Mp.
  • Silent Mode, Multiple Exposure
  • Available in Black, Silver, Tan
  • Manufacturer price $799 for 12-32mm kit, UK - £509 body only, £599 with 12-32mm

  • Cheaper and better offer (unlimited ones!) at

GH5 Panasonic camera, from anticipation to love or hate Tue, 16 Jun 2015 07:59:40 -0600 RRRoger 13179@/talks/discussions image


  • 20Mp m43 CMOS sensor, no AA, 1.7x faster compared to GH4
  • 5 axis sensor based in-body image stabilization, 5 stops specified
  • in-camera waveform monitor and vector scope
  • 480fps AF sensor mode (only for prefocus and photos)
  • 200k actuations shutter, so GH5 is more in line with competition
  • Customisable My menu
  • 3.68Mdot EVF
  • 1.62Mdot 3.2" touch LCD
  • 2 SD slots, UHS-II compatible
  • 4k at 60,50,30,25 and 24fps, no cropping
  • 420 8-bit only at 4k p60
  • 422 10-bit mode for 4k 40fps and below video
  • 400Mbps All-I, 150Mbit IBC for 4K, but ir comes only with future firmware update
  • 1080p24 to 1080p180
  • VLOG will cost you extra $100
  • 6k photo mode at 30fps, continuous focus and exposure tracking enabled
  • 4k photo mode at 60fps
  • Splash, dust, freezeproof, magnesium alloy body
  • USB 3.1 gen 1 via USB-C connector
  • Wi-Fi 802.11a/b/g/n/ac, Bluetooth v4.2
  • Full-sized HDMI port with 4:2:2 10 bit output
  • 138.5mm x 98.1mm x 87.4 mm
  • 645g (bare), 725g (with card and battery)
  • $1999 for body


Camera page


Video modes



GH5 Firmware Update - Performance Enhancement Wed, 17 Jan 2018 16:33:14 -0700 Mckinise 18808@/talks/discussions Yosuke Yamane-san - the head of imaging at Panasonic talks about if required they would release a firmware update for the GH5.

The statement begins at 3:30. He talks about the GH5s being created because they listened to consumers. Then at 3:45 he says that if required they would release a firmware update for the GH5.

What Realistic Features would you like added to the GH5 via firmware update?

Panasonic G80 / G85 / G8 4K 5-axis stab magnesium monster Tue, 16 Aug 2016 06:30:43 -0600 Vitaliy_Kiselev 15524@/talks/discussions image


  • 16mp m43 CMOS sensor without low pass filter
  • Sensor based 5-axis stabilization, around 5 stops
  • Improved 2.36Mpix OLED EVF
  • 3" 1Mdot LCD
  • Dual IS to work with lens IS improved to V2
  • 4kp30, p24, 1080p60,p50 recording in MP4 up to 100Mbit, recording with 422 color encoding
  • 422 recording, but not 10 bit as GH5, only 8bit
  • 9fps shooting
  • SD card slot with latest UHS support
  • Usual Panasonic DFD tech
  • Microphone socket, headphone socket
  • Dust and water proof, magnesium body

PV Deals

  • Body (black PAL, non EU, no limit) - $880 $799
  • 14-140mm Kit (black PAL, non EU, no limit) - $1180 $1099

Both at

US Amazon


Leica CL Camera Topic Tue, 21 Nov 2017 07:19:34 -0700 Vitaliy_Kiselev 18292@/talks/discussions image



Xiaomi Xiaoyi YI-M1 m43 camera, 4K video, $299 only now for kit Tue, 13 Sep 2016 18:40:53 -0600 Vitaliy_Kiselev 15720@/talks/discussions image


  • Sensor - m43 20Mp IMX269 by Sony (same as in latest Panasonic cameras)
  • 81 AF points
  • 3840 × 2160 30fps 70Mbit, 2048 × 1536 30fps 30Mbit, 1920 × 1080 60fps video H.264, 30Mbit
  • Peaking for video
  • 1.04mdot LCD touch screen
  • 1/4000s ~ 60s shutter speed
  • 1/125s flash sync, external flash
  • 5fps burst shooting
  • HDR shooting
  • Wi-Fi, Bluetooth including LE support
  • Remote control via smartphone app
  • SDHC card slot, max size - 512GB
  • USB 2.0 connector, HDMI output
  • Both mike and headphone ports are absent
  • 113.5mm (W) x 64.3mm (H) x 33.6mm (D)
  • 280g
  • standard kit with 12-40mm lens - $329
  • double kit also have 42.5mm F1.8 macro - $449

Panasonic DC GF10 and GF90 Rose Gold Cameras for Girls Tue, 30 Jan 2018 02:50:40 -0700 Vitaliy_Kiselev 18891@/talks/discussions image


  • 16MP m43 sensor, no low pass filter
  • 4K 30p and 24p, 1080p60 video, again fixed by region you buy to PAL or NTSC
  • AF with DFD
  • Optical in lens stabilization only
  • High Speed ​​AF of 0.07 seconds with Space Recognition AF
  • 3" touch LCD screen with 180 degrees tilt and 1.04 million dots
  • “Wide Angle 4K Selphy” that allows you to take pictures of yourself by taking full advantage of lens angle of view
  • New grip
  • “Skin beauty effect”, “People mode”, “Slim mode”
  • Recording media: microSD / microSDHC / microSDXC
  • Weight: Approximately 240 g (body only), approx 270 g (including battery and memory card)
  • Color: Black · White · Orange
  • Wi-Fi 802.11 b/g/n
  • Battery charging only via USB
  • Double lens kit 12-32mm+25mm F 1.7 kit
  • Single lens 12-32mm F3.5-5.6 kit
  • Size: 106.5 mm x 64.6 mm x 33.3 mm
  • Appr. 270 g (including main body, battery, memory card)
  • Appr. 240 g (body only)
  • 90,000 yen price.



Possible Panasonic Production flaw in G7 cameras Wed, 31 Jan 2018 15:47:00 -0700 DrDave 18899@/talks/discussions I have quite a few G7 cameras. A few of these intermittently exhibit some strange behavior where if you press on the mode dial, or in several spots on the back of the camera (where the LCD stores) the mode and the screen jump around rapidly. Popping the back off (easy, but don't do it if you don't know what you are doing) reveals some interesting things. In one corner, and I think this is possibly the problem, there's some small wires that don't quite fit into the clip. They are very thin, so push them into the clip very carefully. Also, be very careful of the ribbon cables.
All of my cameras work perfectly now. After taking the back off, I gently flexed the circuit board towards the lens a few time, reseated the wires in the corner, made sure all the ribbons were in place and fully in their clips, and blew some compressed air into mode dial switch. Not sure which of these fixed the problem, but I suspect it is the wires because some of my cameras have some extra shielding there with a different clip and some do not.
If you do need to pop the back off, make sure to remove the screw in the battery bay and also make sure to remove four screws in the viewfinder. You need to slide off the rubber seal. Again, disassemble only if really needed at your own risk.
When you open the back, you can see that the whole back is a metal heat sink, with a small foam pad in the middle that sits on the hot chip. Inspect that foam as I think it dries out over time if you plan to keep the camera.
To test the (assembled) camera, lightly press the upper right corner of the back where the top of the LCD would go after flipping it out. Try it both in standby and record mode. If nothing happens, leave it be. If under warranty, I recommend factory service over trying to fix it. I suspect there's a design problem that affects some of the cameras.

Panasonic G9 issues topic Sat, 27 Jan 2018 00:41:22 -0700 Eno 18876@/talks/discussions I bought the Panasonic G9, it's nice and all but like any other camera is has issues.

I started a topic where users can write their discovered problems in the hope that someone at Panasonic reads those forums and acknowledges them.

Below I will present what I found wrong on the G9 so far:

  • At higher ISO values I see more than several hot pixels in both Panasonic G9 cameras that I’ve bought. They don’t go away with the Pixel Refresh options (most of them are random). Please Panasonic implement a better way to mask them via a firmware update. It’s really annoying to have hot pixels in my images most of the time. It's hard to understand how important aspect was so easily overlooked!?
  • The auto ISO feature with minimum shutter speed option is not working properly. If for example I chose to set a minimum shutter speed of 1/100 seconds, I expect to get that setting no matter what! In the current implementation, the shutter goes below the limit I set after the camera reaches it's maximum ISO limit and considers it’s too dark. I what my camera to respect my wishes and never go below the minimum shutter speed I set when that setting is on!
  • It doesn't feature at all minimum shutter speed in video mode like the Gh3 and 4 had.
  • The video function flkr reduction can only be activated in still modes and not the video modes. :)) (should I laugh or be sad).
  • I can't set ISO 100 on the auto ISO option, why?
  • The joystick is a nice addition to the camera (in theory), but the way it operates makes it useless for moving the focus point! First, the speed is way too slow, second it only moves horizontally or vertically and we also need it to go in diagonals.
  • The AF (although very quick) in photo mode, in lower light values it hunts a lot and it's not that reliable (I had no problems with the GH4 in the same conditions).
  • Very annoying! In video mode I can't change from the main dial the focus type, continuous or single mode cause Panasonic decided to implement that feature on another menu (burred deep in the video menus) and that overwrites the back AF dial on the camera.
  • In RAW mode at ISO 200 (the so called base ISO in still mode), if the camera is underexposed a bit, the image has a huge magenta cast in the shadows (after exposure recovery). The problem only manifests itself at ISO 200, at ISO 100, 400 etc the camera works properly (I attached an example below). The big problem is that in auto ISO mode, in good light the camera most of the time will chose the minimum ISO 200 (where the problem is). If Panasonic can't correct this, at least they should give the option of ISO 100 in auto ISO mode, to avoid it (somehow).
  • The orange light that illuminates the top LCD fades away after a few seconds even if you are still changing settings that you want to see on the camera.

A small feature request: - Panasonic implemented Luminance levels of 16-255 and 0-235 but not the most useful 16-235 setting (it’s such a pity). Most players and TV's have Luminance values of 16-235 (the one that;s missing from the menu).


Problems not necessarily related to the G9 but important nonetheless cause they affect the manual focus mode:

  • The current implementation of manual focus is close to useless way it is now (sorry but that’s the truth). I wish Panasonic would implement for their Lumix AF lenses, in manual focus mode a distance scale on the camera screen (basically what Fuji does)? There is a scale but without marked distance it's not very usefully. Panasonic AF lenses are grate in AF mode but are a really pain to focus manually. Can somebody at Panasonic please remove the annoying rotation speed sensitivity (or at least give an option to disable it if desire). Coming from manual focus lenses, it's very had to focus with those Lumix AF ones. So basically, I just really wish the option to have a constant reliable rotation of the focus ring (like how manual focus lenses behave) regardless of how fast or slow I turn it (in other words, I want only one speed when turning the focus by wire ring on the lenses). And an option to select the degree of the rotation (like 45, 90, 180 degrees of rotation). I understand the limitations of the continuous AF in video mode but please at least offer us a pleasant manual focus experience.

All above can be dressed in a firmware update if desired.

Panasonic FZ2000 / FZ2500 / FZH1 4K 200Mbit ultrazoom topic Thu, 15 Sep 2016 12:33:52 -0600 Vitaliy_Kiselev 15737@/talks/discussions image


  • 1.0" 20.1mp BSI MOS sensor
  • 24-480mm F2.8-4.5 lens, 16 lenses in 11 groups
  • 9 aperture blades
  • Build in ND filter 0-1/64
  • 2.36mdot OLED EVF, 2.18x magnification (0.74x FF equivalent)
  • 3" 1.04mdot LCD
  • 12fps burst with fixed AF, 7fps continuous AF
  • 4K30p and FHD 60p video recording
  • 4:2:2 10-bit signal HDMI output
  • Wi-Fi
  • SD slot
  • $1199.99 at
  • November 28th release

Panasonic is introducing a second advanced compact camera, the FZ2500. This camera utilizes the same 20.1MP 1" MOS sensor as the LX10, but optimizes video performance with the inclusion of DCI 4K video recording and a true 24 fps frame rate, in addition to more conventional UHD 4K and Full HD recording modes. Also benefitting videographers, this camera includes Panasonic's CINELIKE D and CINELIKE V picture profiles for better grading capabilities, and V-Log L can be added via an optional upgrade. Additionally, high bit rate recording up to 200 Mbps is supported in both MP4 and MOV formats; video can be output over HDMI with a 4:2:2 10-bit signal; there is no recording duration limit; and a built-in ND filter can be used for enhanced control over exposure settings while recording.

More than just a video-optimized camera, however, the FZ2500 also sports a slew of specs for stills and movie users, such as a 50 fps continuous shooting rate with an electronic shutter, or 12 fps with a mechanical shutter, and an expanded sensitivity range of up to ISO 25600 for working in dim light. The built-in 20x Leica DC Vario-Elmarit f/2.8-4.5 lens covers a 24-480mm equivalent focal-length range, and 5-axis HYBRID O.I.S.+ controls the effects of camera shake for sharper handheld shooting. A free-angle 3.0" 1.04m-dot LCD touchscreen permits intuitive control and viewing ease from a variety of working positions, and a 2.36m-dot electronic viewfinder is also available. Additionally, built-in Wi-Fi also supports wireless image sharing and remote camera control.

Workflow HLG HDR to YouTube Fri, 19 Jan 2018 23:32:09 -0700 jonpais 18825@/talks/discussions

GH5 - 180FPS error Sat, 20 Jan 2018 01:33:21 -0700 tired 18826@/talks/discussions Never had a problem shooting 180 before but today at a commercial shoot the 2nd clip went haywire and it only got worse from there

I've included the 1st shot and added stills from some of the other shots so it's clearer whats going on. - pretty weird!

I've tested today and can't replicate the problem, using the latest Sandisc extreme pro v30, formatted in-camera

GH5 Focus Transition things to come Tue, 23 May 2017 05:34:09 -0600 alcomposer 16989@/talks/discussions With the addition of GH5 Focus transition, (a feature borrowed from the AG-DVX200) this has got me thinking:

  • Focus Transition really only works well for lenses that don't breath- or breath minimally.

  • Possibly Panasonic may realise that there is a market for Video Centric MFT lenses

  • Panasonic will have to come out with more Video Centric glass to really utilise this feature. Also ParFocal Zooms would be nice!

  • If Panasonic created a USB-C follow focus protocol (with accompanying hardware- or allowed other companies to make) it would make me much more interested in native Panasonic glass.

  • If Panasonic are 'not' interested in making more Video Centric MFT glass then why put this feature into the GH5 at all? I'm sure it was not simple to code this into the firmware of 'fly-by-wire' lenses.

Does IBIS avoid using a tripod? Is it stable enough with legacy lenses? Sat, 13 Jan 2018 12:57:22 -0700 apefos 18755@/talks/discussions I am wondering if I can avoid the use of tripods, and use IBIS with nikon and canon fd lenses, maybe with a rj focal reducer or a mitakon lens turbo ii.

It would be much faster workflow in the location, and avoid carrying big and heavy stuff.

People who use IBIS can describe your experience?

(I want the shoots most stable possible, just like a tripod)

Panasonic GH5 V 2.0 and up firmware topic Tue, 26 Sep 2017 21:09:33 -0600 Vitaliy_Kiselev 17846@/talks/discussions Topic dedicated to firmware improvements, samples and issues discussion.

Panasonic 180VR hardware add-on? Tue, 09 Jan 2018 17:22:06 -0700 popmechanic 18690@/talks/discussions Today's press release from Google about their VR180 hardware partnerships mentioned that Panasonic is working on a hardware add-on for 180 video support:

"Panasonic is building VR180 support for their just-announced GH5 cameras with a new add-on..."

Does anyone have more info on this?

GH4 4K Panasonic video camera, official topic Tue, 04 Feb 2014 05:05:26 -0700 Vitaliy_Kiselev 9542@/talks/discussions image


  • High speed 16Mp sensor
  • 2.36Mp OLED EVF
  • 1,036Mp OLED screem
  • 4K: 4096×2160 / 24 fps and QFHD 4K: 3840×2160 / up to 30 fps, up to 100Mbps
  • 1080p modes up to 96fps (in variable frame rate), up to 200Mbps I, or 100Mbps IBP modes (see below)
  • peaking with adjustments
  • 422 recording (external)
  • Stills - 12fps constant focus, 7.5fps - with focusing
  • Interface Unit with two XLR, 4 SDI
  • PAL/NTSC switchable
  • Weight with batteries - 560g
  • Dimensions - 133 mm x 93 mm x 84 mm
  • Wi-Fi and NFC
  • Price - unknown yet

Jump to post after official announcement -


We always have stock of GH4 bodies and/or kits,

No time limits like US

Price: click on links below
Shipping: Shipping is around $50 for US/Canada/UK/Australia&NZ/Western Europe. Contact for any other regions.
I want to buy GH4.

Useful links

Available at:

Recording modes:

  • NTSC
    • MOV
      • [4K] 3840×2160, 29.97p, 100Mbps(IPB), LPCM,
      • [4K] 3840×2160, 23.98p, 100Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 59.94p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 29.97p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM,
      • [FHD] 1920×1080, 23.98p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [4K] 3840×2160, 29.97p, 100Mbps(IPB), LPCM/AAC
      • [4K] 3840×2160, 23.98p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 59.94p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 29.97p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 23.98p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 59.94p, 28Mbps(IPB), AAC [FHD] 1920×1080, 29.97p, 20Mbps(IPB), AAC
      • [HD] 1280×720, 29.97p, 10Mbps(IPB), AAC
    • AVCHD
      • [FHD] 1920×1080, 59.94p, 28Mbps(IPB), Dolby Digital
      • [FHD] 1920×1080, 59.94i, 24Mbps(IPB), Dolby Digital (sensor output: 29.97fps)
      • [FHD] 1920×1080, 59.94i, 17Mbps(IPB), Dolby Digital (sensor output: 59.94fps)
  • PAL
    • MOV
      • [4K] 3840×2160, 25.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 50.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 25.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [4K] 3840×2160, 25.00p, 100Mbps(IPB), LPCM/AAC
      • [FHD] 1920×1080, 50.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 25.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
      • [FHD] 1920×1080, 50.00p, 28Mbps(IPB), AAC
      • [FHD] 1920×1080, 25.00p, 20Mbps(IPB), AAC [HD]
      • 1280×720, 25.00p, 10Mbps(IPB), AAC
    • AVCHD
      • [FHD] 1920×1080, 50.00p, 28Mbps(IPB), Dolby Digital
      • [FHD] 1920×1080, 50.00i, 24Mbps(IPB), Dolby Digital (sensor output: 25.00fps)
      • [FHD] 1920×1080, 50.00i, 17Mbps(IPB), Dolby Digital (sensor output: 50.00fps)
  • Cinema
    • MOV
      • [C4K] 4096×2160, 24.00p, 100Mbps(IPB), LPCM
      • [4K] 3840×2160, 24.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 24.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • MP4
      • [C4K] 4096×2160, 24.00p, 100Mbps(IPB), LPCM
      • [4K] 3840×2160, 24.00p, 100Mbps(IPB), LPCM
      • [FHD] 1920×1080, 24.00p, 200Mbps(ALL-Intra)/100Mbps(IPB)/50Mbps(IPB), LPCM
    • AVCHD -
      • [FHD] 1920×1080, 23.98p, 24Mbps(IPB), Dolby Digital


Samples and videos

4K crop calculations:

Stills horizontal resolution - 4608
Cinema 4K horizontal resolution - 4096
4K horizontal resolution - 3840

This makes crop:

  • Cinema 4K - 1,125x
  • 4K - 1,2x

of course, it is additional crop (to 2x typical for m43), so you must multiple two if you need to know relative FF crop.

Previous related topics:

GH5 - HLG workflow & direct rendering HLG to HDR display ??? Sun, 03 Dec 2017 19:54:41 -0700 c3hammer 18383@/talks/discussions Been struggling to find a way to render unedited HLG clips on PC using MPC-HC from a GTX1050x to a Sony XBR43x800D via HDMI 2.0b. It plays back perfectly smooth, but in the flat recorded look. Trying to find a renderer and or shader that will expand the image to proper HDR on my monitor.

Secondarily, looking to see if Resolve 14 Studio, or Edius 9 is the better software for working with this type of HLG and HEVC 6k footage. I've been using Movie Studio 14 and Vegas Pro 14, but it won't work with anything larger than 4K and I need to move on.

Suggestions appreciated. A conversation on the nuances of this new world of HDR would be beneficial for all of us I suppose as well.

Cheers, Pete

Leica TL2 Camera Thu, 13 Jul 2017 05:24:05 -0600 Vitaliy_Kiselev 17337@/talks/discussions image



GH2 stuck mechanical shutter Fri, 09 Jun 2017 16:42:08 -0600 luxis 17122@/talks/discussions Hi all, its been a while I have posted anything. After close to good 6 years my GH2 has its first major issue. The shutter got stuck in closed position taking a photo.

I got the "Please turn camera off and then on again" message. Doing so did not solve the issue. When i do this I hear a slight sound and can see the shutter trying to move slightly but remains like in the first photo.

In the second photo - I tried to manually open it and I saw that another part is stuck behind the outer blades.

My questions: is there a way to find out if its a hardware or software failure. Is it something that can be fixed DIY style or is the camera a paper clip? Does anybody has a official Panasonic Repair Guide/pdf by chance?

I have looked around for a replacement shutter unit (in case it is a hardware failure) and its not exactly easy finding one (comparing to canons and nikons or even gf2/3 which are abundant and cheap etc). Any suggestions and help will be greatly appreciated!

Panasonic GX8 camera official topic Tue, 14 Jul 2015 08:42:41 -0600 Riker 13380@/talks/discussions image

  • 20 Megapixel sensor
  • Dual IS (on sensor and on lens working together)
  • 1/16000 sec High Shutter Speed using Electronic Shutter
  • 2.36 million dot organic EL tilting EVF
  • 21mm Eyepoint LVF for improved usability with glasses
  • Dust and water resistant
  • magnesium alloy body
  • 4K Photo
  • 4K Video
  • Focus Peaking
  • 2.5mm Microphone Socket
  • Silent Mode
  • Free Angle 1.04 million dot organic EL monitor
  • Wi-Fi, NFC, QR code connection
  • Continuous shooting 8 frames / sec in the AF tracking
  • Time Lapse Shot / Stop Motion Animation
  • Body color is black and silver
  • Very good prices for kits on deals -


My lordy lord. Best compact for m43 user ever made? Seems like it. There's no audio jack but who actually cares about that on a camera of this size for its intents and purposes.

Lumix GH5 + HLG + Leeming LUT Downloadable File Thu, 07 Dec 2017 02:33:13 -0700 jonpais 18419@/talks/discussions For downloadable GH5 HLG + Leeming LUT, click here.

Panasonic FZ300 / FZ330 camera official topic Tue, 14 Jul 2015 09:20:12 -0600 Vitaliy_Kiselev 13381@/talks/discussions image
